Spectrophotometer AAS seri AMT3800 seri tertinggi untuk kategori Spektrofotometer dan disini singkatan AAS adalah Atomic Absorption Spectrophotometer.
Fitur Spectrophotometer AAS seri AMT3800 :
- Teknologi cerdas untuk mengukur indeks bias cahaya dan teknologi koreksi otomatis,
- pengukuran otomatis dan dinamis cahaya bias yang terdeteksi tanpa bahan referensi dan biaya peningkatan. Ini meningkatkan instrumen presisi optik. Linier dan koreksi latar belakang secara efektif.
- Asli Optical Noise Reduction, itu meningkatkan kinerja optik instrumen, linier dan peningkatan koreksi.
- Dikembangkan dengan teknologi pengontrol lampu. Itu membuat lampu kathode yang normal lampu mampu menyerap diri dan koreksi latar belakang otomatis mungkin tanpa dan pengaruh terhadap stabilitas instrumen. dan Sementara itu akan bekerja seperti lampu. Biaya lampu hallow katoda yang normal hanya sekitar 1/10 dari lampu khusus.
- Asli “Hg lampu-reagen” pengukuran gradien. pengembang kami menciptakan sebuah model matematika yang tepat untuk memperkirakan spesifikasi “ganda linier balok dan keseimbangan”. Teknologi ini menyediakan metode cepat dan ekonomi untuk sistem pengujian diri instrument. Hal ini juga mendirikan sebuah metode baru untuk meningkatkan kinerja deteksi instrumen.
- Banyak inovasi teknologi dan pembaharuan seperti desain fashion, lampu elemen multi-dimensi sistem penyesuaian otomatis, jalur gas elektronik desain fungsional dan modular, pemegang D-lampu No-penyesuaian dan sebagainya.
Technical Specification | ||||
Model | AMT3801AA | AMT3802AA | AMT3803AA | |
Optical System |
Instrument Type | Single Beam Reflection Achromatic Optics System | ||
Mono Chromometer | Achromatic C-T ,Focus 350mm | |||
Dispersion elements | Grating system 1200line/mm characterization area 40??0mm2 Scintillation wavelength 250nm |
|||
Bandwidth | 0.1,0.2,0.7,1.4mm Adjustable | |||
Wavelength Range | 190-900 | |||
Wavelength Accuracy | +-0.2 | |||
Wavelength Repeatability | 0.1nm max | |||
Resolution | Mn 3lines(279.5 & 279.8 Peak and Valley ??0% | |||
Spectrophotometric |
Measurement | A,T,C | ||
Photometric Range | 0-125%, -0.1-3.00A | |||
Static Baseline Drift | (Cu) +-0.003A/30min | |||
Dynamic Baseline Drift | (Cu) +-0.006A/30min | |||
Background Correction | D-Lamp Background Correction >50times Correction Ability (1Abs) | |||
Atomization System | Flame | Graphite Furnace | Flame/Graphite Furnace | |
Flame | Characteristic Concentration | (Cu) 0.025ug/ml max | —- | (Cu) 0.025ug/ml max |
Detection limit | (Cu) 0.004ug/ml max | —- | (Cu) 0.004ug/ml max | |
Precision | RSD 0.6% max | —- | RSD 0.6% max | |
Burner | titanium | —- | titanium | |
Nebulizer | high-efficient Nebulizer | —- | high-efficient Nebulizer | |
Spray chamber | anticorrosion material | —- | anticorrosion material | |
Safety measures | Flame fuel gas, power assisted gas abnormal pressure protection | —- | Flame fuel gas, power assisted gas abnormal pressure protection | |
Graphite Furnace | Characteristic quantity | —- | Characteristic value Cd 0.5pg max Characteristic value Cu 20pg max |
Characteristic value Cd 0.5pg max Characteristic value Cu 20pg max |
Detection Limit | —- | Detection limit Cd 0.8 pg max | Detection limit Cd 0.8 pg max | |
Precision | —- | Precision Cd , Cu 4% max | Precision Cd , Cu 4% max | |
Temperature Range | —- | Room-temperature~3000°C | Room-temperature~3000℃ | |
High-Power Heating Range | —- | 1500℃ ~ 3000℃ | 1500℃ ~ 3000℃ | |
Ramp time & Holding time | —- | 1s ~ 255s | 1s ~ 255s | |
Heating Rate | —- | Max Heating Rate 2000??S | Max Heating Rate 2000??S | |
Atomization Heating | —- | Optical Control, Time Control,Normal | Optical Control, Time Control, Normal | |
Protect Gas Flow Rate out of Graphite Tube | —- | 1 L/min | 1 L/min | |
Protect Gas Flow Rate in Graphite Tube | —- | 0-50ml/min micro-flow, 300-400ml/min Fixed-Flow | 0-50ml/min micro-flow, 300-400ml/min Fixed-Flow | |
Safety measures | —- | Cooling water flow, Protect Gas Pressure, furnace temperature, Graphite Tube Alarm | Cooling water flow, Protect Gas Pressure, furnace temperature, Graphite Tube Alarm | |
Data Process | Test Manner | Flame, Graphite Furnace, hydride-AA, flame emission | ||
Concentration | standard curve, standard addition, interpolation | |||
Times of repetitive | Measurement 1-30times, Average Value of A&C | |||
Report Print | parameters, data result | |||
Other | PC | exteriorization | ||
Dimension (mm) | 790 x 600 x 540 | 790 x 600 x 540 | 790 x 600 x 540 x 2 | |
Weight (kg) | 70 | 70 | 70+70 | |
Power Supply | (220±22)V, (50±1)Hz | |||
Temperature range | 10℃ ~ 30℃ | |||
Humidity range | 40% ~ 85% |
Note: AMT3803AA = AMT3801AA + AMT3802AA, technical specifications, profile and configuration may changed without notice
